Operating angle

Approx. ±42.5°（From center position）

Operating force

Approx. 3.5N~5N

Max. operating force

100N

Mechanical life expectancy

Approx. 10,000,000

Operating temperature range

-20℃~+85℃

Storage temperature range

-20℃~+85℃

Mass

Approx. 300g

Protection grade

IP54

Standard resistance value

10K±15%

Independent linearity tolerance

±3%

Output smoothness

Against input voltage 0.2%

Contact resistance variation

<5%CRV

Resolution

Essentially infinite

Power rating

0.2W

Dielectric strength

1 min (500V.A.C.)

Insulation resistance

>1000MΩ (500V.D.C.)

EMS

10V/m (80MHz~1GHz 1KHz 80%)

Special knob

Special knob and motifs on the knob

Other special specifications

With customer-specific connectors；With protection module
