Multi Switch type
Knob configured with 6 up to 8 push button switches
Switch type
6 button switches at most and 1 DEAD-MAN switch
Thumb joystick type
1 thumb joystick, 2 button switches at most and 1 DEAD-MAN switch
Matching joystick
SAKAE: 50JC SENTOP: JP50、JH50；SAKAE: 90JA、90JB ；Other joystick；Be used alone"
Operating force
Approx. 3.1N
Applied voltage
5V±0.01V
Output signal
0～5V（Available for other output ranges）
Life expectancy
>1,000,000
Protection degree
IP68
Type
Button switch；DEAD-MAN switch
Rating
48V.D.C. / 0.1A；30V.D.C. / 0.1A
Life expectancy
Approx. 100,000；Approx. 100,000
Insulation resistance
>1000MΩ (500V.D.C.)；>100MΩ (500V.D.C.)
Dielectric strength
1min (1000V.A.C.)；1min (600V.A.C.)
Protection degree
IP67 ；IP40
