Single turn
Wirewound
Bushingmount
Standard Resistance Range
100Ω～20KΩ
Max. Practical Resistance Value
50KΩ
Total Resistance Tolerance
Standard Class ±10%(K), Precision Class ±5%(J)
Independent Linearity Tolerance
Standard Class ±1.0%, Precision Class ±0.5%
Power Rating
5.0W
Noise
<100Ω E.N.R.
Electrical Travel
280°±5°
Mechanical Travel
300°±5°
Insulation Resistance
>100MΩ(1000V.D.C.)
Dielectric Strength
1 minute at 1,000V.A.C.
Starting Torque
<30mN·m(300gf·cm)
Stopper Strength
Approx.0.9N•m(9kgf•cm)
Resistance Temperature Coefficient
±20p.p.m./℃
Mass
Approx.330g
Special shaft type
Shaft dia. (φ 6.35mm)&bushing with inch dimension, special machining on the shaft, shaft with front and rear extension (Rear shaft with 6mm dia. and 25mm length)
Special electrical travel
Special electrical travel
Special tap
Extra tap (Available up to 1 tap)
Without stopper
Electrical travel remains 280°± 5°
Special gangs
Multi-ganged (Available up to 2 gangs)
