Time: 2023-01-09
Hall effect joystick
1-dimensional coordinate type joystick
Low-cost
Controlling range of operating lever
1-dimensional coordinate type ±20°～±25° from center position.
Operating force
Standard spring return device : Automatically return to center, Approx.1～2.5N(100～250gf), (With rubber cover: Approx.1～5.5N(100～550gf))
Operating temperature range
-20℃～+60℃
Vibration
10～55Hz 98m/S2
Shock
294m/s2
Mechanical life expectancy
Approx.5,000,000 operations
Mass
Approx.100g
Type
Hall effect IC type resistive element incorporated
Applied voltage
5V±10% D.C.
Effective output
Approx. 0.5V～4.5V
Independent linearity tolerance
±3%
Load resistance
＞10KΩ
Dielectric strength
1 minute at 250V.A.C.
Insulation resistance
>100MΩ（250V.D.C.）
EMS durability
50V/m( 80MHz～1GHz 1KHz sine-wave 80%AM modulation)
