Hall effect miniature thumbstick
2-dimensional coordinate
Controlling range of operating lever
Omni-directionally approx. ±17° from center position
Operating force
Spring return device (Automatically return to center), X&Y directions: Approx. 1N～2.5N
Operating temperature range
-20℃～+60℃
Vibration
10～55Hz 98 m/s2
Shock
294 m/s²
Mechanical life expectancy
Approx. 2,000,000 operations
Mass
Single output type: Approx. 22g, Dual output type: Approx. 24g
Applied voltage
5VDC±10%
Effective output
0.5V～4.5V
Electrical rotating angle
X&Y directions: Approx. ±17° (Approx.34°)
Independent linearity tolerance
±3%FS
Load resistance
>10KΩ
Dielectric strength
1 minute at A. C. 500V
Insulation resistance
>1000MΩ（500V.D.C）
EMS durability
100V/m (80MHz～1GHz 1kHz sine-wave 80%AM modulation)
ESD durability
±8kV contact ±15kV aerial discharge (Based on IEC61000-4-2)
