Protection degree

IP54

Operating torque

<1mN·m

Max. rotation speed

<6000rpm

Life expectancy

Approx.100,000,000

Mass

Approx.18g

Housing material

Anodized aluminium alloy

Shaft material

Stainless steel

Operating temperature range

-40℃～+125℃

Storage temperature range

-40℃～+125℃

Standard model

EI22A-S1

Applied voltage

3.3V-5V

Output high level

>VDD-0.5V

Output low level

<0.5V

Output form

Push-pull output

Number of output pulse

4096 ppr max.

Mechanical angle

360° (Endless)

Output propagation delay

<10μs

Current consumption (no-load)

<28mA

Insulation resistance

> 1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

EMS durability

10V/m (80MHz～1GHz 1kHz sine-wave 80%AM modulation)

ESD durability

±8KV contact ±15KV aerial discharge (Based on IEC61000-4-2)

Special shaft

Special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.)
