Compact product
Optional detent in the middle position
Several optional operating angle
Optional switch signal
Operating angle
±50°、±135°、±160°
Operating force
Abt.5N~15N
Stoper Strength
120N
Mechanical life expectancy
10,000,000
Mass
Approx.350g
Operating temperature range
-30℃~+85℃
Protection degree
IP65(above panel）
Standard model
HW62W-10K-100-2
Potentiometer model
SFCP22E
Independent linearity tolerance
±3%
Standard resistance value
10K±15%
Effective electrical angle
100°±5°
Power rating
0.2W
Resolution
Essentially infinite
Detent
0~3pcs of detent is available according to customers' request, such as center position detent , end position detent, etc.
Special dial
Dial can be customized according to customer request.
Mark on dial
The mark on dial could be printed according to customer's request by laser printer. The indicated location of the mark can be specified according to customer requirements.
Special mechanical structure
We can provide middle position self-locking products.
