Standard Resistance Range

1K,2K,5K,10K(Ω)

Special Practical Resistance Values

500,20K,50K,100K,200K (Ω)

Total Resistance Tolerance

Standard Class ±10%(K)

Independent Linearity Tolerance

Standard Class ±0.5%, Precision Class ±0.25%, Super Precision Class ±0.1%

Resolution

Essentially infinite

Output Smoothness

<against input voltage 0.1%

Contact Resistance

<2%C.R.V.

Power Rating

2.0W

Electrical Travel

340°±5°

Mechanical Travel

360°(Endless)

Insulation Resistance

>1000MΩ(1000V.D.C.)

Dielectric Strength

1 minute at 1,000V.A.C.

Starting Torque

<3mN·m(30gf·cm)

Resistance Temperature Coefficient

±400p.p.m./℃

Mass

Approx.60g

Special shaft type

Shaft with front and rear extension (Rear shaft with 6mm dia. and 15mm length), shaft dia. (φ 6.35mm) with inch dimension, special machining on the shaft

Special electrical travel

Special electrical travel

Special tap

Extra tap (Available up to 3 taps)

With stopper

Rotating angle is 320°and stopper strength is 0.9N・m [9kgf・cm]

Special gangs

Multi-ganged (Available up to 7 gangs, Housing length is extended by 12mm per 1 gang)
