Mechanical angle

360º (Endless)

Protection degree

IP40

Operating torque

<1mN·m

Life expectancy

20,000,000

Mass

Approx.90g

Bearing

With one couple of precision ball bearings

Housing material

Anodized aluminium alloy

Shaft material

Stainless steel

Wiper material

Precious metal multi-finger wiper

Operating temperature range

-55℃～+125℃

Storage temperature range

-55℃～+125℃

Shock

50G 11ms

Vibration

15G/10Hz ~ 2000Hz

Standard resistance

1K,2K,5K,10K

Resolution

Essentially infinite

Resistance tolerance

±15%

Independent linearity tolerance

Standard ±0.2%; Precision ±0.1%

Electrical angle

355°±2°

Power rating

2W

Wiper current

μA～1mA(Max.2mA)

Insulation resistance

≥1000MΩ(500V.D.C.)

Dielectric strength

500V.A.C/1 min

Output smoothness

<0.1%against input voltage

Resistance temperature coefficient

±400P.P.M/°C

Special specifications

Special resistance, Special electrical angle, Special machining on the shaft.
